New original Fuji TK-N2P 24-36A thermal relay TR35BEWP-C thermal protection TK-N2PE-C

SKU: New original Fuji TK-N2P 24-36A thermal relay TR35
0.0 (0)
0 Sold
$55.00 $60.00
New original Fuji TK-N2P 24-36A thermal relay TR35BEWP-C thermal protection TK-N2PE-C
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
  • New original Fuji TK-N2P 24-36A thermal relay TR35BEWP-C thermal protection TK-N2PE-C
  • New original Fuji TK-N2P 24-36A thermal relay TR35BEWP-C thermal protection TK-N2PE-C
1/1
  • New original Fuji TK-N2P 24-36A thermal relay TR35BEWP-C thermal protection TK-N2PE-C
  • Description

New Original Fuji TK-N2P 24-36A Thermal Relay (with TR35BEWP-C and TK-N2PE-C Models)

Overview

The Fuji TK-N2P 24-36A Thermal Relay series, encompassing models TR35BEWP-C and TK-N2PE-C, is engineered as a critical protective component for industrial motor circuits. Manufactured by Fuji Electric, a globally recognized leader in electro-mechanical systems, this thermal overcurrent relay is designed to safeguard three-phase AC motors against overheating and excessive current draw.

Core Functionality

At its operational essence, this relay monitors the current flow within motor circuits. Utilizing a precision bimetal trip mechanism, it activates when preset current thresholds are exceeded—tripping the associated contactor to disconnect the motor. Primary applications include industrial pumps, conveyor systems, compressors, and HVAC equipment, ensuring operational reliability and longevity.

Technical Features

1. Accurate Thermal Protection

  • Detects phase imbalances and overloads with consistency.
  • Adjustable trip settings (24-36A nominal range) for application-specific customization.
  • Fast-response bimetal element minimizes motor stress under fault conditions.

2. Consistent Tripping Performance

  • Maintains ±10% trip time tolerance as per IEC/EN standards.
  • Reset options include manual or automatic configurations depending on model specifications.

3. Original Fuji Quality Assurance

  • Manufactured under ISO-certified processes.
  • All components undergo stringent thermal cycling and dielectric testing.
  • Conforms to IEC 60947-4-1, UL 508, and CE directives for safety compliance.

4. Model-Specific Specifications

| Model | TR35BEWP-C | TK-N2PE-C |
|------------------|----------------|----------------|
| Trip Range | 24-36A | 24-36A |
| Contact Type | Single-Pole | Single-Pole |
| Mounting | DIN Rail | DIN AC max | 690V AC max |

General Performance Ratings

  • Rated Insulation Voltage: 750V AC
  • Thermal Withstand: 110% overload × 2 hours (IEC)
  • Mechanical Life: ≥ 1,000,000 operations
  • Ambient Temperature: -25°C to +55°C

Applications & Integration

Designed to pair with Fuji SC-series contactors or industry-standard magnetic starters. Factory automation, material handling systems, and energy infrastructure projects leverage its fail-safe configuration for minimal downtime.

Selecting the Protection Relay

✅ Why Choose Fuji TK-N2P Series?

  • Reliability: Original Fuji components guarantee lifecycle consistency.
  • Compatibility: DIN-rail mounting interfaces with global control panel designs.
  • Industry Trust: Developed by Fuji’s Electrical Components Division—specialists in motor protection since the 1960s.

Ordering Reference
Specify exact model requirement:

  • TK-N2P 24-36A Base Relay
  • TR35BEWP-C | TK-N2PE-C for configuration variants

📌 Validate authenticity via Fuji Electric’s official part number registry or trusted distributors to avoid counterfeit risks.


romised thermal safety.
