When it comes to safeguarding your electrical circuits, compromise is not an option. The **ve ratings: 6A, 10A, 16A, 20A, 25A, 32A, and 40A) delivers the rigorous protection and operational reliability that professional electricians and facility managers demand. Engineered with a *double-in, double-out (2P) configuration* within a compact 1P+N footprint, this device ensures that both the live and neutral conductors are simultaneously disconnected, providing a true full-isolation solution for single-phase systems.
Complete Disconnection for Enhanced Safety
Unlike standard 1P breakers that only interrupt the phase conductor, the iDPNa’s double-pole switching mechanism breaks both the line and neutral. This eliminates residual voltage risks during maintenance or fault conditions—a critical feature for installations where equipment grounding is uncertain or where user safety is paramount.
Precision C-Curve Tripping Characteristics
The C-curve (6 to 10 times rated current) is specifically calibrated for mixed resistive and inductive loads, making it ideal for general-purpose lighting, socket outlets, and small motor circuits. This ensures nuisance-free operation under normal inrush currents while reacting decisively to short-circuit events.
Wide Amperage Range for Flexible Application
With seven available ratings—from 6A for lighting sub-circuits to 40A for high-demand appliances—the iDPNa family adapts seamlessly to residential, commercial, and light industrial distribution boards. Each unit undergoes rigorous testing to meet Schneider’s global quality benchmarks, guaranteeing consistent performance across varying load profiles.
Space-Saving, Tool-Free Installation
The modular 18mm width per pole fits standard DIN rails, allowing for high-density panel design without sacrificing wiring clarity. Dual-terminal clamps on both the input and output sides accept solid or stranded conductors up to 25mm², reducing installation time and ensuring a secure, low-resistance connection.
Every iDPNa breaker features a robust thermal-magnetic trip mechanism, housed in a flame-retardant, impact-resistant casing (IP20 rated). The clear visual indicator on the toggle provides instant status recognition, while the padlockable handle (optional accessory) adds an extra layer of lockout/tagout compliance for industrial environments. Whether you are upgrading an existing panel or designing a new distribution system, this breaker offers the double-in, double-out isolation that modern electrical codes increasingly require—without compromising on footprint or cost-efficiency.
Choose the Schneider iDPNa. Because precision protection is not just a feature—it’s a standard.
