60-1Two00C/T-P2-15V TS5209NFour50Brand newJapanese Technical Encoder
Output ABZ. The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
2Number of pulses100-200-.512.600-1024.2500-3600p/r
4Output Form:Open collector output, push-pull output, long-line drive output
The encoder body is fixed by shrapnel.
Parameters: Optional number of pulses, DC5V-30V power supply, maximum mechanical speed 8000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output: Output circuit hasNPN(PNP) collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)General type
Purpose: Printer, Servo Motor, CNC Machine Tool, Elevator, Door Machine
