SE100-102Four-Forty-2PTaiwanSUMMITFujita elevator encoder
outputABZ. The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
Parameters:Inner hole:Phi40Mm;
2Number of pulses:100-200-.512.600-1024.4096-5400P/r
4Output Form:Open collector output, push-pull output, long-line drive output
Encoder bodyUseThe shrapnel is fixed;
use Path: Asynchronous Elevator Speed Control and Industrial Automation Control
Excellent Point: Stable performance, strong anti-interference
Parameters: The number of pulses is optional.DC5V-30V power supply, maximum mechanical speed 8000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output:The output circuit hasNPN(PNP) collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)General type
Purpose:Servo Motor, CNC Machine Tool, Elevator, Door Machine
