LHD-022-512New LiEncoder
Output ABZ. The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
Parameters: Optional number of pulses, DC 5V power supply, maximum mechanical speed 8000 rpm, response frequency: 0-300 KHz, consumption current: <150MA.
Output: Output circuit hasNPN(PNP) collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)(Note: There is no voltage output when the collector is not connected with pull-up resistance)
Purpose: Servo motor, CNC machine tool, elevator, motor
