HTR-OS-500-2-C
outputABZ。 The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
Outside diameter:32mmAxis diameter:4-5-6 mm
The synchronous flange of the encoder body is fixed.
pulse1-2500Signal output:TLLandHTLoutput
Voltage:DC 5V-30V
Parameters: The number of pulses is optional.DC5V-30VPower supply, maximum mechanical speed 12000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output:The output circuit hasNPN(PNP) collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)General type
Purpose:Servo Motor, CNC Machine Tool, Elevator, Door Machine, Loran
