E6B2-CWZ5B 100 p'r
outputABZ。 The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
Parameters: The number of pulses is optional.DC5VPower supply, maximum mechanical speed 12000 rpm, response frequency: 0-300KHz, consumption current: <120MA. Pulse from Minimum 5cp-2500cpr
Size:Encoder body size: external diameter 38mm; shaft 6mm; length 15mm. With D-notch, fixed hole is: 6-M3 screw hole - PCD28, 30 universal
Output:output circuitYesNPN(PNP)Open-circuit output type of collector"Voltage type, complementary type and long-line driving type（RS422)General type(Note: When the collector is not connected with pull-up resistance, there is no voltage output)
Purpose:Servo Motor, CNC Machine Tool, Elevator, Door Machine, Industrial Control Automation Equipment
