TS5Two26N103 OIH100-512C/T-P2-15V ElevatorEncoderSuccedaneum
Output ABZ. The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
2Number of pulses:100-200-.512.600-1024.4096-5400P/r
4Output Form:Open collector output, push-pull output, long-line drive output
Encoder bodyUseThe shrapnel is fixed;
use Path: Asynchronous Elevator Speed Control and Industrial Automation Control
Excellent Point: Stable performance, strong anti-interference
Parameters: Optional number of pulses, DC5V-30V power supply, maximum mechanical speed 8000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output: Output circuit hasNPN(PNP) collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)General type
Purpose: Servo motor, CNC machine tool, elevator, door machine
