New folderIGV28-0007 PP-36-ABO-E7-2-5 rotary encoder shaft 5mm36 line
outputABZ. The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
axis/holePath:10-8-6-5-4The synchronous flange of the encoder body is fixed.
pulse10-20-36-100-200-500-1000Signal output:TLLandHTLoutput
Voltage:DC5V-30V;10-30V, 5V
Parameters: The number of pulses is optional.DC5V-30V power supply, maximum mechanical speed 12000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output:The output circuit hasNPN(PNP collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)General type
Usage: Hydraulic shears,Servo Motor, CNC Machine Tool, Elevator, Door Machine, Steel Works
