Product Introduction: ME1469-N-100-B3V-LC HandheldME1469-N-100-B3V-LC Handheld Pulse Incremental Encoder** is a precision-engineered portable solution designed for industrial automation, motion control calibration, and system diagnostics. As a compact, high-reliability device, it delivers accurate pulse generation for testing, troubleshooting, and validating encoder-driven systems. Ideal for engineers and technicians, this encoder combines ruggedness with advanced functionality in a user-friendly handheld format.

Key Features

1. High-Resolution Pulse Output

• 100 Pulses Per Revolution (PPR): Ensures precise incremental signal generation for fine motion control calibration.
• Quadrature (A/B) Output: Provides industry-standard 90° phase-shifted signals for direction and velocity detection.

2. Portable & Ergonomic Design

• Handheld Form Factor: Enables easy operation in confined spaces or during field maintenance.
• Integrated Rotary Handle: Facilitates smooth manual rotation with tactile feedback.

3. Robust Industrial Construction

• Durable Enclosure: Engineered to withstand harsh environments (IP-rated protection pending specifications).
• EMI/RFI Shielding: Minimizes signal interference in electrically noisy settings.

4. Versatile Compatibility

• 5V TTL/CMOS Logic: Compatible with PLCs, CNCs, servo drives, and data acquisition systems.
• Standard Connectorization: Features quick-connect interfaces (e.g., M12 or flying leads) for seamless integration.

5. Low-Power Operation

• 3V DC Supply: Optimizes energy efficiency for extended battery-powered use (battery not included).

Technical Specifications

| Parameter | Specification |
|--------------------|-----------------------------------|
| Model | ME1469-N-100-B3V-LC |
| Type | Incremental Encoder (Handheld) |
| Resolution | 100 PPR |
| Output Signal | A, B, Z (Index) + Vcc/GND |
| Supply Voltage | 3V DC (±10%) |
| Output Type | Push-Pull / Line Driver |
| Interface | 5-pin Circular Connector (e.g., M12) |
| Operating Temp.| -10°C to +70°C |
| Protection | IP64 (Dust/Water Resistant) |

Applications

• System Commissioning: Verify encoder input functionality on PLCs/motion controllers.
• Maintenance & Troubleshooting: Simulate encoder feedback to diagnose faults.
• Training & Education: Demonstrate encoder principles in technical workshops.
• Prototyping: Test motion algorithms without deploying full-scale hardware.

Why Choose the ME1469-N-100-B3V-LC?

This encoder eliminates downtime by enabling rapid validation of automation systems. Its precision, portability, and industrial durability make it indispensable for professionals seeking to enhance productivity and ensure system integrity.

Ready to Optimize Your Workflow?
Contact our sales team today for volume pricing, datasheets, and custom configurations. Elevate your diagnostic capabilities with the ME1469-N-100-B3V-LC—engineered for accuracy, built for the field.
